ASUS PRIME B760-PLUS D4 ATX Motherboard – LGA1700, DDR4, PCIe 5.0

Description

ASUS PRIME B760-PLUS D4 ATX Motherboard

The ASUS PRIME B760-PLUS D4 is an ATX motherboard designed for desktop builds using compatible Intel processors and DDR4 memory. Built around the Intel B760 chipset and an LGA1700 CPU socket, it supports Intel Core 14th, 13th and 12th Gen processors, plus supported Pentium Gold and Celeron CPUs. Always check ASUS’s CPU support list and the installed BIOS version for your exact processor.

Key Features

• Intel B760 chipset and LGA1700 socket: for compatible Intel desktop processors.
• DDR4 memory: four DIMM slots, dual-channel support, up to 128GB of non-ECC unbuffered memory, and Intel XMP support. Supported speeds depend on the CPU and memory configuration; higher speeds may require overclocking.
• PCIe expansion: one PCIe 5.0 x16 slot for graphics, one PCIe 4.0 x16-length slot operating at up to x4, and two PCIe 3.0 x1 slots.
• Flexible storage: three M.2 Key M slots and four SATA 6Gb/s ports for compatible SSDs and hard drives.
• Fast wired networking: Realtek 2.5Gb Ethernet.
• Rear display outputs: DisplayPort 1.4, HDMI 2.1 and VGA. Display output availability depends on the installed CPU’s graphics capabilities; DisplayPort and HDMI support up to 4K at 60Hz as specified by ASUS.
• USB connectivity: rear USB-C 3.2 Gen 2×2, two USB-A 3.2 Gen 2, one USB-A 3.2 Gen 1 and two USB 2.0 ports, plus internal headers for front-panel USB.
• Audio and cooling features: Realtek 7.1-channel HD audio, M.2 heatsink and VRM heatsink design.
• DIY-friendly features: ASUS Q-Design, Q-LED Core, SafeSlot Core+, Aura Sync headers and a Thunderbolt/USB4 header.

Technical Specifications

• Model: ASUS PRIME B760-PLUS D4
• Form factor: ATX, 30.5 × 24.4 cm
• CPU socket: Intel LGA1700
• Chipset: Intel B760
• Memory: 4 × DDR4 DIMM, up to 128GB, dual-channel, non-ECC unbuffered, Intel XMP
• Expansion slots: 1 × PCIe 5.0 x16, 1 × PCIe 4.0 x16-length (x4 mode), 2 × PCIe 3.0 x1
• Storage: 3 × M.2 Key M slots, 4 × SATA 6Gb/s
• Network: Realtek 2.5Gb Ethernet
• Rear display connectors: DisplayPort 1.4, HDMI 2.1, VGA
• Wireless: a vertical M.2 Key E slot is provided; Wi-Fi/Bluetooth module is sold separately.
• Audio: Realtek 7.1 Surround Sound HD Audio CODEC

Compatibility Notes

This is a DDR4 motherboard; it does not use DDR5 memory. The Wi-Fi module is not included as standard according to ASUS’s specification page. Confirm CPU support, memory compatibility, case ATX support and the exact included accessories before purchase.
